VENTILATOR 5V/DC VAPOLAGER 40X40X6MM 10.7M3/H 39.3DBA
€ 13,55
€ 11,20
Artikelnummer
F0504006VB
- ArtikelnummerF0504006VB
- MerkSUNON
- Aantal 5+ € 12,20 € 10,08
Design
Motor: | Patented One-phase Single Coil |
DC Brushless Motor Design | |
Nr. of Motor Poles: | 4 |
Frame, Impeller: | Filled Thermoplastic PBT (UL94V-0) |
Bearing System: | Vapo |
With Magnetic Levitation System | |
Lead Wire: | AWG28, Stripped, Tinned |
Technical Specifications |
Rated Voltage: | 5V DC |
Operating Voltage: | 2,5...5,5V DC |
Dielectric Strength at 65% r. F.: | 500V AC for 1 Min. |
Insulation Resistance at 500V DC : | 10MOhm |
Storage Temperature: | -40...+70°C |
Operating Temperature: | -10...+70°C |
Part Nr. | URated | PAirflow | Noise | I | Pel | Speed |
[V] | [m3/h] | [dBA] | [A] | [W] | [RPM] | |
MF40060V1-A99 | 5 | 10,02 | 29,9 | 0,087 | 0,44 | 7000 |
