DIN-RAIL 35MM VOEDING 30W 24V/1.5A
€ 20,07
€ 16,59
Artikelnummer
HDR3024
- ArtikelnummerHDR3024
- MerkMEANWELL
- Aantal 3+ € 19,07 € 15,76
Features
| • Direct assembly on DIN Rail • Enclosed case, Touch-guard screw terminals • Universal input • Overload protection, current limiting, auto recovery • Protections: short circuit/over load/over voltage • Low no load power consumption • Power-on LED display • Insulation Class II |
 |
| Technical Specifications |
|
|
| Input Voltage: | 85...264V AC (47...63Hz) |
| 120...370V DC | |
| Input Inrush Current, Max.: | 45A |
| Over Load Protection: | 105...160% |
| Withstand Voltage, I/P-O/P: | 3000V AC |
| Operating Temperature: | -30...+70°C |
| Weight: | 120g |
| I/P = Input, O/P = Output |
|
|
|
| Part Nr. | UA | IA | PA | DUA | URN | h |
| [V] | [A] | [W] | [%] | [mVp-p] | [%] | |
| HDR-30-5 | 5 | 0...3 | 15 | 2 | 80 | 82 |
| HDR-30-12 | 12 | 0...2 | 24 | 1 | 120 | 88 |
| HDR-30-15 | 15 | 0...2 | 30 | 1 | 120 | 89 |
| HDR-30-24 | 24 | 0...1,5 | 36 | 1 | 150 | 89 |
| HDR-30-48 | 48 | 0...0,75 | 36 | 1 | 240 | 90 |
| UA = Output Voltage, IA = Output Current Range, PA = Output Power, DUA = Output Voltage Tolerance, URN = Ripple & Noise, h = Efficiency | ||||||
