DIN-RAIL 35MM VOEDING 30W 15V/2A

MEANWELL
Artikelnummer: HDR3015
Uw prijs:
€ 16,49 Excl. BTW:
€ 19,95 Incl. BTW:
- +

Extra informatie

print

Features

• Direct assembly on DIN Rail
• Enclosed case, Touch-guard screw terminals
• Universal input
• Overload protection, current limiting, auto recovery
• Protections: short circuit/over load/over voltage
• Low no load power consumption
• Power-on LED display
• Insulation Class II
Technical Specifications

Input Voltage: 85...264V AC (47...63Hz)
120...370V DC
Input Inrush Current, Max.: 45A
Over Load Protection: 105...160%
Withstand Voltage, I/P-O/P: 3000V AC
Operating Temperature: -30...+70°C
Weight: 120g
I/P = Input, O/P = Output


Part Nr. UA IA PA DUA URN h
  [V] [A] [W] [%] [mVp-p] [%]
HDR-30-5 5 0...3 15 2 80 82
HDR-30-12 12 0...2 24 1 120 88
HDR-30-15 15 0...2 30 1 120 89
HDR-30-24 24 0...1,5 36 1 150 89
HDR-30-48 48 0...0,75 36 1 240 90
UA = Output Voltage, IA = Output Current Range, PA = Output Power, DUA = Output Voltage Tolerance, URN = Ripple & Noise, h = Efficiency
