ZUIVERE SINUS OMVORMER 24VDC-230VAC 250W

€ 158,99 € 131,40
Artikelnummer
NTS250-224
  • ArtikelnummerNTS250-224
  • MerkMEANWELL
  • Aantal 2+   € 143,09 € 118,26
Print deze pagina Print deze pagina

Features

• Enclosed design
•True sine wave output (THD<3%)
• Peak power up to 500W
• Adjustable output voltage
• Remote function
• Shutdown when battery is too low
• Alarm function in case of low battery voltage
• Protections: short circuit, overvoltage and overtemperature
• Safety standards: IEC 62368-1
• EMC standards: EN55032 Class A
• 3 years manufacturer's warranty
Technical Specifications

Output voltage, selectable: 200/220/230/240V AC
Output voltage tolerance: ±3%
Output frequency: 50/60Hz
Output frequency tolerance: ±0,1%
Output power: 250
Waveform: True Sine Wave, THD <3%
Connection type: Plug-in connector
Operating temperature range -20...+70°C
Insulation voltage I/P-O/P: 3000 V AC
Insulation voltage O/P-FG: 1500 V AC
Dimensions: 186x100,5x32mm
Weight: 750g

Part No. Nominal input voltage UE IE h
  [V] [V] [A] [%]
NTS-250P-212 12 10...16,5 25 92
NTS-250P-224 24 20...33 13 93
NTS-250P-248 48 40...66 7 93
UE = Input voltage range, IE = Input current, h = Efficiency
