USB ADAPTER HIGH GAIN WIRELESS N

•11N speed allows for the best HD video streaming and internet calling experience
•Dual external antennas deliver enhanced reception and transmission performance
•Easy one-touch wireless security encryption with the Quick Security Setup button
•1.5 meter USB extension cable enables convenient, flexible deployment
•Supports Windows XP / Vista / 7


HARDWARE FEATURES

Interface: Mini USB 2.0
Button: QSS Push Button/Software
Dimensions ( W x D x H ):90 x 68 x 16.8mm
Antenna Type: Dual Omni Directional
Antenna Gain: 3dBi

WIRELESS FEATURES
Wireless Standards: IEEE 802.11n, IEEE 802.11g, IEEE 802.11b
Frequency: 2.400-2.4835GHz

Signal Rate
11n: Up to 300Mbps(dynamic)
11g: Up to 54Mbps(dynamic)
11b: Up to 11Mbps(dynamic)

EIRP: <20dBm(EIRP)

Reception Sensitivity
270M: -68dBm@10% PER
130M: -68dBm@10% PER
108M: -68dBm@10% PER
54M: -68dBm@10% PER
11M: -85dBm@8% PER
6M: -88dBm@10% PER
1M: -90dBm@8% PER

Wireless Modes: Ad-Hoc / Infrastructure mode
Wireless Security: Support 64/128 bit WEP, WPA-PSK/WPA2-PSK
Modulation Technology: DBPSK, DQPSK, CCK, OFDM, 16-QAM, 64-QAM
Advanced Functions: WMM
