DIN-RAIL VOEDING 63MM 240W 48V/5A

Single and two phase wide input range 180 ~ 550VAC
Protections: Short circuit / Overload / Over voltage / Over temperature
Cooling by free air convection
Built-in constant current limiting circuit
Can be installed on DIN rail TS-35/7.5 or 15
EN61000-6-2(EN50082-2) industrial immunity level
100% full load burn-in test
Built-in DC OK relay contact


Technical Specifications
Input Voltage: 180...550V AC (47...63Hz) 254...780V DC
Input Inrush Current, Max.: 50A

uitgangsspanning:48V +/-1.0%
uitgangsstroom: 5A
max. vermogen: 240W
afmetingen: 63 x 125,2 x 113,5mm
gewicht: 1060g
werktemperatuur: -25°C ~ 70°C
