VOEDING 13,8V DC 35A MAX.

Technische specificates:

• Operating voltage: 230 V AC / 50 Hz
• Output voltage: 13.8 volts DC fixed voltage
• Output current constant: 35 Ampère
• Ripple & noise: <50mVss, 5mVrms
• Load regulation: <100mV for load changes from 0-100%
• Control input voltage: <20mV change in the input voltage to + / -10%
• Indicator: LED lamp on the front (red / green)
• DC jacks:
  2  x 4mm banana socket with screw / clamp design on the back
  1 x Cigarette lighter socket on the front
• Cooling: Fan
• Protections:
  Overcurrent (overload)
  Short circuit Constant current (short circuit protections by Constant Current Circuit)
  Over voltage from 16.5V (Output Over Voltage Protection)
  Overheating (over temperature)
• Zero voltage switching capability technology
• Dark gray metal housing
• Rubber feet
• PFC Power Factor Control
• Cable with plug and IEC connector included
• Dimensions (WxHxD): 175x72x195 mm
• Weight: 1.8 kg
