VLAKTRANSFORMATOR 1VA 2X12V 2X41MA

Construction

• Vacuum encapsulated, bobbin with two chambers
• Leads through soldering pins to accommodate PCB mounting
• Designed to match VDE 0570 and EN61558 regulations
• Fully tested at primary and secondary voltage of 6000V, leakage and sparking distance in air is at least 10mm
• Types with double primary and secondary windings (2x115V) suitable for application in 115V as well as 230V power supplies

Dimensions: (lxBxH)33,4x28.9x14,5mm

Input: 230VAC
Output: 2x6VAC 2x41mA
