VENTILATOR 230V/AC KOGELLAGER 120X120X38MM 164M3/H 45DBCONNECTOR AANSLUITING
€ 24,59
€ 20,32
Artikelnummer
F2312038BD
- ArtikelnummerF2312038BD
- MerkSUNON
- Aantal 5+ € 22,12 € 18,28
Design
 |
|
| Motor: | Shaded-Pole Motor, Impedance Protected |
| Frame: | Aluminium Spray Cast |
| Impeller: | Filled Thermoplastic PBT (UL94V-0) |
| Connection Type: | See Table Below |
|
|
| Technical Specifications |
|
|
| Rated Voltage: | 230V |
| 220V | |
| Operating Voltage: | 185...245V |
| Dielectric Strength at 65% r. F.: | 1800V AC for 1 Min. |
| Insulation Resistance at 500V DC: | >500MOhm |
| Storage Temperature: | -40...+70°C |
| Operating Temperature: | -10...+70°C |
|
|
| Part Nr. | Bearing | Terminal | PAirflow | Noise | I | Pel | Speed |
| Type | Type | ||||||
| [m3/h] | [dBA] | [A] | [W] | [RPM] | |||
| A2123HBT | B | T | 164,76 | 45 | 0,14 | 23 | 2700 |
