TRANSFORMATOR 1.5VA 1X18V 1X83MA

€ 4,65 € 3,84
Artikelnummer
1180015M
  • Artikelnummer1180015M
  • MerkHAHN
  • Aantal 5+   € 4,17 € 3,45
Print deze pagina Print deze pagina
Features
• Winding of double coated copper wire for better insulation, vacuum casted, two chambers
• Connections for PCB use
Technical Specifications

Temperature Resistance Class1): Ta 70/F
End Temperature in Case of Short Circuit, Max2): 190°C
End Temperature in Standard Use: 140°C
Permissible Overtemperature3): 70K
Primary Voltage (50/60Hz): 230V AC
Power, Max. (Ta 70/F)2): 1,5VA
Test Voltage: 4kV/50Hz
No-Load Voltage (According to VDE 0570): <2 x UN sec
1) The Maximum Permissible Continuous Ambient Temperature Applies in the Event of Short-Circuit, 2) Taking into Account the Indicated Temperature Resistance Class, 3) At 70°C Ambient Temperature
