DIN-RAIL 110MM VOEDING 960W 48V/20A
€ 299,00
€ 247,11
Artikelnummer
TDR96048
- ArtikelnummerTDR96048
- MerkMEANWELL
- Aantal 3+ € 284,05 € 234,75
Three-Phase 340 ~ 550VAC wide range input
(Dual phase operation possible)
Width only 110mm
High efficiency 94.5% and low power dissipation
Protections: Short circuit / Overload / Over voltage / Over temperature
Cooling by free air convection
Built-in constant current limiting circuit
Can be installed on DIN rail TS-35/7.5 or 15
UL508(industrial control equipment)approved
EN61000-6-2(EN50082-2) industrial immunity level
Current sharing up to 3840W(3+1)
Built-in DC OK relay contact
100% full load burn-in test
Built-in active PFC function compliance to EN61000-3-2
Technical Specifications
Input Voltage: Three-Phase 340 ~ 550VAC (Dual phase operation possible) 480 ~ 780VDC
Input Inrush Current, Max.: 60A
uitgangsspanning: 48V +/-1.0%
uitgangsstroom: 20A
max. vermogen: 960W
afmetingen: 110 x 125,2 x 150mm
gewicht: 2,47kg
werktemperatuur: -30°C ~ 70°C
