PRESIDENT TAYLOR IV DM AM/FM

€ 209,95 € 173,51

Artikelnummer

TAYLORIV

27Mhz transceiver 40 kanalen AM/FM 4W

Toon meer Toon minder

ArtikelnummerTAYLORIV
MerkPRESIDENT

Aantal 3+ € 199,44 € 164,83

Een moderne President-radio met veel functies verpakt in een klassieke uitstraling. Nu inclusief President Digimike met NRC en functies zoals 7 verschillende displaykleuren, USB-oplaadpunt, klassieke analoge S-meter, menufuncties, PA-hoornaansluiting, 12/24 dubbele spanning en nog veel meer.

Frequentiebereik: 26,965 - 27,405 MHz

Features

Modulation: AM / FM
Multi-bands: Yes
Output power: 4 Watt
Channels: 40 AM / FM
Display type: LCD display
Display colors: Green / Orange / Purple / Blue / Cyaan / Yellow / Clear Blue
VOX Function: Yes
USB: Yes
Noise blanker: Yes
Squelch: ASQ (Automatiq Squelch Systeem) / Manual squelch /
Emergency channel: Yes
Scan function: Yes
External speaker socket: Yes
External PA socket: Yes
S-meter: Yes
Digimike with NRC: Yes
Display: Multi-functions / Frequencies
Talkback function: Yes
Key beep: Yes
Roger beep: Yes
Microphone type: Electret / Dynamic
F / Menu function key: Yes
SWR (Power Reading / SWR): Yes
Filter HI-CUT: Yes
Dimmer: Yes
External VOX jack: Yes

Electrical data

Voltage: 13,8 Volt / 24 Volt /

Transmitter

Audio frequency response: 300 Hz - 3 kHz
Microphone sensitivity: 1,0 mV
Frequency allowance: +/- 300 Hz
Transmission interference: inferior to 4 nW (- 54 dBm)
Emitted power in the adjacent channel: inferior to 20 μW
Drain: 1.7 A (with modulation)
Modulated signal distortion: 1,8 %

Receiver

AM sensitivity: 0.5 μV - 113 dBm
FM sensitivity: 0.5 μV - 113 dBm
Frequency response: 300 Hz - 3 kHz
Adjacent channel selectivity: 60 dB
Maximum audio power: 5 Watt
Squelch sensitivity: minimum 0.2 μV - 120 dBm / maximum 1 mV - 47 dBm
Frequency image rejection rate: 60 dB
Intermediate frequency rejaction rate: 70 dB
Drain: 500 mA nominal / 800 mA maximum

Mechanical data

Length: 150 mm
Height: 45 mm
Width: 165 mm
Weight: 750 gram
Antenna connector: UHF (PL) female (SO-239)
Microphone connector: 6 pin

Inside the box

Transceiver: 1 pcs
Fixing screws: 1 set
Mounting bracket: 1 pcs
Power lead: 1 pcs
User Manual: English, Spanish, French, Polish
Digimike NRC: 1 pcs
