DIN-RAIL VOEDING 32MM 75W 12V/6,3A
€ 44,95
€ 37,15
Artikelnummer
SDR7512
- ArtikelnummerSDR7512
- MerkMEANWELL
- Aantal 3+ € 42,70 € 35,29
Part Number SDR-75-12
Wattage 76
Input Voltage (V) 88~264VAC, 124~370VDC
Output Current (A) 0~6.3
Output Voltage (V) 12
Output Voltage Options Single
DC output adjustment 12~14V
Working Temperature -30 ~+70°C (Refer to \"Derating Curve\")
Safety Standards UL508, TUV EN60950-1 approved, design refer to GL
EMC Standards Compliance to EN55022 (CISPR22) Class B, EN61000-3-2,-3, EN61000-4-2,3,4,5,6,8,11, EN55024, EN61000-6-2 (EN50082-2), EN61204-3, heavy industry level, criteria A, SEMI F47 approved
Dimensions (LxWxH) mm 32x 125.2x 102
Wattage 76
Input Voltage (V) 88~264VAC, 124~370VDC
Output Current (A) 0~6.3
Output Voltage (V) 12
Output Voltage Options Single
DC output adjustment 12~14V
Working Temperature -30 ~+70°C (Refer to \"Derating Curve\")
Safety Standards UL508, TUV EN60950-1 approved, design refer to GL
EMC Standards Compliance to EN55022 (CISPR22) Class B, EN61000-3-2,-3, EN61000-4-2,3,4,5,6,8,11, EN55024, EN61000-6-2 (EN50082-2), EN61204-3, heavy industry level, criteria A, SEMI F47 approved
Dimensions (LxWxH) mm 32x 125.2x 102
