DIN-RAIL VOEDING 480W 48V/10A

High efficiency 94% and low power dissipation
150% peak load capability
Built-in active PFC function, PF>0.94
Protections: Short circuit / Overload / Over voltage / Over temperature
Cooling by free air convection
Built-in constant current limiting circuit
Can be installed on DIN rail TS-35/7.5 or 15
UL 508(industrial control equipment)approved
EN61000-6-2(EN50082-2) industrial immunity level
Built-in DC OK relay contact
100% full load burn-in test

Technical Specifications
Input Voltage: 90 ~ 264VAC / 127 ~ 370VDC
Input Inrush Current, Max.: 80A

uitgangsspanning: 48V +/-1.0%
uitgangsstroom: 10A
max. vermogen: 480W
afmetingen: 85,5 x 125,2 x 113,5mm
gewicht: 1,6kg
werktemperatuur: -25°C ~ 70°C
