DC/DC CONVERTER 36-48V -> +3,3V 5A 16,5W

DC VOLTAGE: +3,3VDC
RATED CURRENT: 5,0A
CURRENT RANGE: 0 ~ 5,0A
INPUT VOLTAGE: 36-72VDC
RATED POWER: 16,5W


Wide 2:1 DC input range
In/Out capacitance 1000pF
Protections: Short circuit/Over load/Over voltage
1000VDC I/O isolation for D/D
Cooling by free air convection
Built-in remote ON/OFF control
100% full load burn-in test
Fixed switching frequency at 225KHz
High reliability/low cost
