DC/DC CONVERTER 18-36V -> +12,0V 2.5A 30W
€ 39,95
€ 33,02
Artikelnummer
SDM30/24S1
- ArtikelnummerSDM30/24S1
- MerkMEANWELL
- Aantal 5+ € 35,95 € 29,71
DC VOLTAGE: +12VDC
RATED CURRENT: 2,5A
CURRENT RANGE: 0 ~ 2,5A
INPUT VOLTAGE: 18-36VDC
RATED POWER: 30W
Wide 2:1 DC input range
In/Out capacitance 1000pF
Protections: Short circuit/Over load/Over voltage
1000VDC I/O isolation for D/D
Cooling by free air convection
Built-in remote ON/OFF control
100% full load burn-in test
Fixed switching frequency at 225KHz
High reliability/low cost
RATED CURRENT: 2,5A
CURRENT RANGE: 0 ~ 2,5A
INPUT VOLTAGE: 18-36VDC
RATED POWER: 30W
Wide 2:1 DC input range
In/Out capacitance 1000pF
Protections: Short circuit/Over load/Over voltage
1000VDC I/O isolation for D/D
Cooling by free air convection
Built-in remote ON/OFF control
100% full load burn-in test
Fixed switching frequency at 225KHz
High reliability/low cost
