DC-DC CONVERTER 19-36V:48V 4.2A IN BEHUIZING
€ 119,00
€ 98,35
Artikelnummer
SD200B48
- ArtikelnummerSD200B48
- MerkMEANWELL
- Aantal 3+ € 107,10 € 88,51
2:1 wide input range
Protections: Short circuit / Overload / Over voltage / Over temperature
1500VAC I/O isolation
Cooling by free air convection
100% full load burn-in test
OUTPUT
DC VOLTAGE: 48V
RATED CURRENT: 4,2A
CURRENT RANGE: 0 ~ 4,2A
RATED POWER: 201.6W
VOLTAGE ADJ. RANGE: 43 ~ 53VDC
INPUT
VOLTAGE RANGE: 19 ~ 36VDC
DC CURRENT: 10.4A/24V
Dimension: 215x115x50mm
Protections: Short circuit / Overload / Over voltage / Over temperature
1500VAC I/O isolation
Cooling by free air convection
100% full load burn-in test
OUTPUT
DC VOLTAGE: 48V
RATED CURRENT: 4,2A
CURRENT RANGE: 0 ~ 4,2A
RATED POWER: 201.6W
VOLTAGE ADJ. RANGE: 43 ~ 53VDC
INPUT
VOLTAGE RANGE: 19 ~ 36VDC
DC CURRENT: 10.4A/24V
Dimension: 215x115x50mm
