DC-DC CONVERTER 19-36V:24V 8.4A IN BEHUIZING
€ 119,12
€ 98,45
Artikelnummer
SD200B24
- ArtikelnummerSD200B24
- MerkMEANWELL
- Aantal 3+ € 107,21 € 88,60
2:1 wide input range
Protections: Short circuit / Overload / Over voltage / Over temperature
1500VAC I/O isolation
Cooling by free air convection
100% full load burn-in test
OUTPUT
DC VOLTAGE: 24V
RATED CURRENT: 8,4A
CURRENT RANGE: 0 ~ 8,4A
RATED POWER: 201.6W
VOLTAGE ADJ. RANGE: 23 ~ 30VDC
INPUT
VOLTAGE RANGE: 19 ~ 36VDC
DC CURRENT: 10.4A/24V
Dimension: 215x115x50mm
Protections: Short circuit / Overload / Over voltage / Over temperature
1500VAC I/O isolation
Cooling by free air convection
100% full load burn-in test
OUTPUT
DC VOLTAGE: 24V
RATED CURRENT: 8,4A
CURRENT RANGE: 0 ~ 8,4A
RATED POWER: 201.6W
VOLTAGE ADJ. RANGE: 23 ~ 30VDC
INPUT
VOLTAGE RANGE: 19 ~ 36VDC
DC CURRENT: 10.4A/24V
Dimension: 215x115x50mm
