GESCHAKELDE VOEDING SINGLE OUTPUT 1200W 5V/240A
€ 499,00
€ 412,40
Artikelnummer
RSP150005
- ArtikelnummerRSP150005
- MerkMEANWELL
- Aantal 3+ € 474,05 € 391,78
| Features |
| • Enclosed case, built-in fan, screw terminals • Universal input • Overload protection, current limiting, hiccup after 5s • Protections: short circuit/over load/over voltage • Built-in active PFC function • Low profile • Parallel function • Active current sharing up to 6000W (3+1 units) • Built-in remote On/Off control • Power fail signal • Built-in remote sense function • Built-in auxiliary power 12V/0,1A • EMC: Conducted Emission EN55032/EN55011 Class B, Radiated Emission EN55032/EN55011 Class A |
 |
| Technical Specifications |
|
|
| Input Voltage: | 90...264V AC (47...63Hz) |
| 127...370V DC | |
| Input Inrush Current, Max.: | 60A |
| Leakage Current, Max.: | 2mA |
| Output Voltage Adjustment: | ±10% |
| Over Load Protection: | 105...135% |
| Withstand Voltage | |
| I/P-O/P: | 3000V AC |
| I/P-FG: | 2000V AC |
| O/P-FG: | 500V AC |
| Operating Temperature: | -20...+70°C |
| Weight: | 3000g |
| I/P = Input, O/P = Output, FG = Frame Ground |
|
|
|
| Part Nr. | UA | IA | PA | DUA | URN | h |
| [V] | [A] | [W] | [%] | [mVp-p] | [%] | |
| RSP-1500-5 | 5 | 0...240 | 1200 | 2 | 150 | 80 |
| RSP-1500-12 | 12 | 0...125 | 1500 | 1 | 150 | 87 |
| RSP-1500-15 | 15 | 0...100 | 1500 | 1 | 150 | 87 |
| RSP-1500-24 | 24 | 0...63 | 1512 | 1 | 150 | 90 |
| RSP-1500-27 | 27 | 0...56 | 1512 | 1 | 150 | 90 |
| RSP-1500-48 | 48 | 0...32 | 1536 | 1 | 200 | 91 |
| UA = Output Voltage, IA = Output Current Range, PA = Output Power, DUA = Output Voltage Tolerance, URN = Ripple & Noise, h = Efficiency | ||||||
