TRAFO RINGKERN PRINT 2 X 15V 2 X 107MA 3,2VA
€ 19,95
€ 16,49
Artikelnummer
RPT03215
- ArtikelnummerRPT03215
- MerkTALEMA
- Aantal 5+ € 17,96 € 14,84
Technical Specifications
Power: 3,2VA
Primary Voltage (50/60Hz): 2x115V
Secondary Voltage : 2 x 15V 2 x 107mA
Efficiency: 70%
No-Load Current, I0typ.: 1,5mA
Test Voltage (Prim./Sec.): 4,0kV
Temperature Class: T60/E
Temperature Rise: 20K
Protection, 230V, Delayed Fuse: 32mA
Insulation Class: A(105°C); E(125°C)
Power: 3,2VA
Primary Voltage (50/60Hz): 2x115V
Secondary Voltage : 2 x 15V 2 x 107mA
Efficiency: 70%
No-Load Current, I0typ.: 1,5mA
Test Voltage (Prim./Sec.): 4,0kV
Temperature Class: T60/E
Temperature Rise: 20K
Protection, 230V, Delayed Fuse: 32mA
Insulation Class: A(105°C); E(125°C)
