RELAIS 24VDC 4 X MAAK/2 X BREEK 8A
€ 27,95
€ 23,10
Artikelnummer
R024D4M2B
- ArtikelnummerR024D4M2B
- MerkTE CONNECTIVITY
- Aantal 5+ € 25,16 € 20,79
Features |
• Relay with forcibly guided contacts according to EN50205 • 6-pole safety relay • Category of protection RTIII (wash tight) |
Application |
Emergency shut-off, press control, safety modules, elevator and escalator control |
Technical Specifications |
Contact | |
R024D4M2B: | 4xNO+2xNC |
R024D5M1B: | 5xNO+1xNC |
R024D3M3B: | 3xNO+3xNC |
Contact Material: | AgSnO2 |
Rated Current: | 8A |
Max. Switching Voltage: | 400V AC |
Max. Switching Power: | 2000VA |
Creepage/Clearance: | 5,5/5,5mm |
Testing Voltage | |
Coil/Contact: | 3000Vrms |
Contact/Contact: | 3000Vrms |
Opening Contact: | 1500Vrms |
Lifetime | |
Mechanical: | 10x106 Operations |
Operating Temperature: | -25...+70°C |
Weight Approx.: | 30g |
Coil Data |
Part Nr. | UN | UAn | UAb | PN | RN |
[V DC] | [V] | [V] | mW | Ohm | |
R024D4M2B | 24 | 18 | 2,4 | 1200 | 480 |
R024D5M1B | 24 | 18 | 2,4 | 1200 | 480 |
R024D3M3B | 24 | 18 | 2,4 | 1200 | 480 |
UN = Rated Voltage, UAn = Operate Voltage, UAb = Release Voltage, PN = Rated Power, RN = Coil Resistance; All Specifications Measured at 23°C |
