RELAIS 1 X MAAK 12VDC 5A 720 OHM
€ 2,95
€ 2,44
Artikelnummer
R012D1MR
- ArtikelnummerR012D1MR
- MerkFUJITSU
- Aantal 5+ € 2,65 € 2,19
Features
| • Slim type with 7mm width • High switching current • High insulation: min. 6mm between coli and contact • Cadmium free contacts • Wash tight construction RTIII |
 |
| Technical Specifications |
|
|
| Contact: | SPST-NO |
| Contact Material | |
| FTRF3AA_HA: | AgNi |
| Rated Switching Current | |
| FTRF3AA_HA: | 5A |
| Max. Switching Voltage | |
| FTRF3AA_HA: | 277V AC / 30V DC |
| Max. Switching Power: | 750VA / 90W |
| Creepage/Clearance | |
| FTRF3AA_HA: | 6/6mm |
| Operate/Release Time: | 10/10ms |
| Testing Voltage | |
| Coil/Contact (1min.): | 4000V AC |
| Open Contact (1min.): | 750V AC |
| Min. Lifetime | |
| Mechanical: | 5x106 Operations |
| Electrical | |
| FTRF3AA_HA: | 200x103 Operations |
| Operating Temperature | |
| FTRF3AA_HA: | -40...+70°C |
| Weight Approx. | |
| FTRF3AA_HA: | 4g |
