LAMP SIGNAAL E10 RAFI ORANJE

General information
Colour of lens amber
Form of lens round
Diameter of collar 20 mm

Dimensions
Overall height 15.5 mm
Mounting depth 33 mm
Mounting hole 16.2 mm

Electrical characteristics
Power limit max. 2 W
Voltage limit max. 250 V

Mechanical design
Terminals screw terminals nickel-plated
Mounting ring nut
Lamp socket E 10
Lamp filament lamp

Other specifications
Approvals at 2W (T=°C) VDE, SEV T 70°C
Weight 11 g
Degree of protection from front side IP40
