RELAIS 230VAC/28K OHM/5MA 1 X WISSEL 250VAC/16A STEEK/SOLDEERLIPPEN

Features
• Socket mount or direct connection via Faston connectors
• AC coils & DC coils sensitive (500mW)
• Available with: lockable test button, mechanical indicator
• Relays protection class RTII

RELAY, SPCO, 16A, 230VAC
Relay Type: Miniature
Coil Voltage VAC Nom: 230V
Contact Current Max: 25A
Contact Voltage AC Nom: 250V
Coil Resistance: 28kohm
Contact Configuration: SPDT
Coil Type: AC
Coil Current: 45mA
Nom Operating Power: 1.2VA
Relay Mounting: Quick Connect
External Height: 32.8mm
External Width: 29mm
External Depth: 12.4mm
SVHC: No SVHC (18-Jun-2012)
Approval Bodies: CSA / GOST / RINA / VDE
Approval Category: UL Recognised
Contact Current AC Max: 25A
Contact Current Rating: 16A
Contact Material: AgNi
Contact Voltage AC Max: 250V
Dielectric Voltage Contact to Contact: 1000V AC
External Length / Height: 32.8mm
Mounting Type: Plug-In
No. of Electrical Operations: 100000
No. of Mechanical Operations: 10000000
No. of Pins: 5
No. of Poles: 1
Operating Temperature Max: 70°C
Operating Temperature Min: -40°C
Operating Time: 15ms
Release Time: 5ms
Series: 46
Switching Voltage AC / DC Max: 440V AC
Terminal Type: 4.8mm x 0.5mm
