RELAIS PRINT 1XOM 24VDC 1440 OHM SCHAKELVERMOGEN 10A/250VAC

Features
• Sensitive coil: 400mV
• 2kV Coil/Contact
• Flux protected enclosure
• Withstands impulse of up to 4500V

Technical Specifications
Contact: SPDT (Circular Contact)
Contact Material: AgSnO2
Rated Current: 10A
Max. Switching Current: 10A
Max. Switching Voltage: 250V AC
Max. Switching Power: 1200VA
Creepage/Clearance: 3,3/2,7mm
Operate/Release Time: 10/5ms

Testing Voltage
Coil/Contact: 2000V
Contact/Contact: 750V

Lifetime
Mechanical: 10x106 Operations
Electrical: 10x104 Operations
Operating Temperature: -40...+85°C
Weight Approx.: 12g

Rated Voltage: 24Vdc
Maximum Operating Voltage: 31,2Vdc
Operate Voltage: 18Vdc
Release Voltage: 2,4Vdc
Rated Current: 16,7mA
Rated Power: 400mW
Coil Resistance: 1440 Ohm
Specifications Measured at 23°C
