RELAIS 24VDC 1 X WISSEL 400VAC/6A 3350 OHM PRINT
€ 9,95
€ 8,22
Artikelnummer
R024D1WR
- ArtikelnummerR024D1WR
- MerkFINDER
- Aantal 5+ € 8,94 € 7,39
Features
Ultra-slim (5mm)
High-density mounting due to low dimensions
Low power consumption
High dielectric strength, low coil consumption
Protective separation according to VDE 0106, EN 50178, EN 60204 to Contact and Coil
DC drive
Protection class II to VDE 0631 / EN 60730
Technical Specifications
Contact: SPDT
Contact Material
F3451-_: AgNi
Rated Current: 6A
Max. Switching Current: 10A
Max. Switching Voltage: 400V AC
Max. Switching Power
AC1/230V: 1500VA
AC15/230V: 300VA
Creepage/Clearance: 8/8mm
Operate/Release Time: 5/3ms
Testing Voltage
Coil/Contact: 4000V AC
Opening Contact: 1000V AC
Lifetime
Mechanical: 10x106 Operations
Electrical: 60x103 Operations
Operating Temperature: -40...+85°C
Ultra-slim (5mm)
High-density mounting due to low dimensions
Low power consumption
High dielectric strength, low coil consumption
Protective separation according to VDE 0106, EN 50178, EN 60204 to Contact and Coil
DC drive
Protection class II to VDE 0631 / EN 60730
Technical Specifications
Contact: SPDT
Contact Material
F3451-_: AgNi
Rated Current: 6A
Max. Switching Current: 10A
Max. Switching Voltage: 400V AC
Max. Switching Power
AC1/230V: 1500VA
AC15/230V: 300VA
Creepage/Clearance: 8/8mm
Operate/Release Time: 5/3ms
Testing Voltage
Coil/Contact: 4000V AC
Opening Contact: 1000V AC
Lifetime
Mechanical: 10x106 Operations
Electrical: 60x103 Operations
Operating Temperature: -40...+85°C
