RELAIS PRINT 5VDC 167R 1 X WISSEL 125VAC/1A
€ 2,95
€ 2,44
Artikelnummer
R005D1WE
- ArtikelnummerR005D1WE
- MerkOMRON
- Aantal 5+ € 2,65 € 2,19
Features
Wash tight construction
Wide switching capacity: 1mA...1A
Highly sensitive coil: 150mW
Insertable in a 10-pole IC socket
Conforms to FCC (part 68) requirements for coil to contacts
Technical Specifications
Contact: SPDT (Single Crossbar)
Contact Material: Silver, Gold-Plated
Rated Current: 1A
Max. Switching Voltage: 125V AC / 60V DC
Switching Power: 30W / 62,5VA
Operate/Release Time: 5/5ms
Testing Voltage (50/60Hz; 1 Min.)
Coil/Contact: 1000V AC
Lifetime
Mechanical: 5x106 Operations
Electrical: 1x105 Operations
Operating Temperature: -40...+70°C
Weight Approx.: 2g
