POTMETER MONO LIN 6MM AS 100E 1W IP64
€ 12,50
€ 10,33
Artikelnummer
E100P11
- ArtikelnummerE100P11
- MerkVISHAY
- Aantal 5+ € 11,24 € 9,29
Technical Specifications
 |
|
| Power Rating (TU = 70°C): | 1W |
| Hold-off Voltage: | 350V |
| Dielectric Strength (RMS): | 1500V |
| Insulation Resistance, Min.: | 106MOhm |
| Standard Tolerance: | ±10% |
| Resistive Element: | Cermet |
| End Resistance (Typ.): | 2Ohm |
| Electrical Travel: | 270° ±10° |
| Mechanical Travel: | 300° ±5° |
| Operating Torque, Max.: | 0,4...1,8Ncm |
| Stop End Torque, Max.: | 80Ncm |
| Temperature Range: | -55...+125°C |
| Temperature Coefficient (Typ.): | ±150ppm/°C |
| Climatic Category: | 55/125/56 |
| Sealing: | IP64 |
|
|
| Part Nr. | R | PMax. | UMax. | IMax. |
| Ohm | [W] | [V] | [mA] | |
| E100P11 | 100 | 1 | 10 | 100 |
| E500P11 | 500 | 1 | 22,4 | 44,7 |
| K001P11 | 1K | 1 | 31,6 | 31,6 |
| K005P11 | 5K | 1 | 70,7 | 14,1 |
| K010P11 | 10K | 1 | 100 | 10,0 |
| K050P11 | 50K | 1 | 224 | 4,47 |
| K100P11 | 100K | 1 | 316 | 3,16 |
| K500P11 | 500K | 0,25 | 350 | 0,7 |
| M001P11 | 1M | 0,12 | 350 | 0,35 |
| R = Resistance, PMax. = Power, Max. (+70°C), UMax. = Operating Voltage, Max., IMax. = Transmission Current, Max. | ||||
|
||||
| Norms |
| CECC41000 |
