POLYESTERFOLIE 10N 100V 5MM
€ 0,48
€ 0,40
Artikelnummer
MKT110
- ArtikelnummerMKT110
- MerkKEMET
- Aantal 10+ € 0,44 € 0,36
Features
| • Dielectric, polyester film (polyethylene terephthalate) • Box material is solvent resistant and flame retardant according to UL94V-0 • Tinned wire leads • Low attenuation • High pulse rating |
 |
| Technical Specifications |
|
|
| Rated Voltage (UN): | See Table |
| Test Voltage (2s; 25±5°C): | 1,4xUN |
| Capacitance Tolerance (1kHz): | ±10% |
| Temperature Range: | -55...+105°C |
| Climatic Category | |
| IEC 60068-1: | 55/100/56 |
| Insulation Resistance, Min. | |
| to incl. 330nF: | 15GOhm |
| 330nF...1µF: | 5000s |
| from 1µF: | 1000s |
| Pulse Rise Time, Max. (du/dt) | |
| 100V DC: | 100V/µs |
| 63V DC: | 70V/µs |
| Reliability (MIL HDB 217) (40°C, 0,5 x UN): | 1,0fit1) |
| 1) 1fit = 1x10 -9 Failure Components/Hour | |
