NETFILTER RFI 0.5A 230V PRINT

€ 12,75 € 10,54
Artikelnummer
FN402-0.5
  • ArtikelnummerFN402-0.5
  • MerkSCHAFFNER
  • Aantal 5+   € 11,47 € 9,48
Print deze pagina Print deze pagina
Features
• Single phase PCB-mounting filters
• Low profile

Technical Specifications

Continuous Operating Voltage, Max.: 250V AC, 50/60Hz
Dielectric Strength, 2s
Line To Ground: 2kV AC
Line To Ground B-Type: 2,5kV AC
Line To Neutral: 0,76kV AC
Temperature Range: -25...+100°C

Part Nr. IR L CX CY IL
  [A] [mH] [nF] [nF] [µA]
FN402-0,5 0,5 40 100 2,2 373
FN402-1 1 10 100 2,2 373
FN402-1,6 1,6 6 100 2,2 373
FN402-2,5 2,5 2 100 2,2 373
FN402-4 4 1 100 2,2 373
FN402-6,5 6,5 1 100 2,2 373
IR = Rated Current, at 40°C, L = Inductance, IL = Leakage Current, Max. at 230V, 50Hz
Approvals
   14
