MICROSWITCH 1XOM 3A/250VAC IP67 MET HENDEL
€ 5,75
€ 4,75
Artikelnummer
MS57-L
- ArtikelnummerMS57-L
- MerkBrand
- Aantal 10+ € 5,17 € 4,27
Features
Different actuators
Long operating live due to an incorporated snapping mechanism made with two highly precise split springs
Protection class IP67
Supplied with 30cm long connecting leads
Electrical Specifications
Switching Capacity: 3A, 250V AC/5A, 125V AC/3A, 30V DC
Contact Resistance, Max.: 50mW
Insulation Resistance (500V DC), Min.: 100MW
Dielectric Strength, Min.: 1000V AC
Technical Specifications
Nr. of Contacts: SPDT
Operating Temperature: -40...+85°C
Operating Life
Mechanical: 5x106 Switches
Electrical: 10x104 Switches
Different actuators
Long operating live due to an incorporated snapping mechanism made with two highly precise split springs
Protection class IP67
Supplied with 30cm long connecting leads
Electrical Specifications
Switching Capacity: 3A, 250V AC/5A, 125V AC/3A, 30V DC
Contact Resistance, Max.: 50mW
Insulation Resistance (500V DC), Min.: 100MW
Dielectric Strength, Min.: 1000V AC
Technical Specifications
Nr. of Contacts: SPDT
Operating Temperature: -40...+85°C
Operating Life
Mechanical: 5x106 Switches
Electrical: 10x104 Switches
