MOMENT 1XOM 230VAC/3A IP40 M22 VERLICHTING KNOP BLAUW
€ 37,99
€ 31,40
Artikelnummer
MSMCS22-BL
- ArtikelnummerMSMCS22-BL
- MerkSCHURTER
- Aantal 5+ € 34,19 € 28,26
Features
| • High-quality Stainless steel housing • Highly durable ceramic actuator with homogeneous illumination • Vandal-proof according to IP69K • For use in harsh environment • High-quality design • Reliable tactile feedback of input |
 |
| Technical Specifications |
|
|
| Material | |
| Housing: | Stainless Steel |
| Actuator: | Ceramic |
| Contacts: | Silver-plated |
| Switching Voltage, Max.: | 250V AC |
| Switching Current, Max.: | 3A, 250V AC/5A, 125V AC |
| Switching Capacity, Max.: | 1250W |
| Contact Resistance: | <30mOhm |
| Insulation Resistance: | <100MOhm |
| NO Pulse Time: | <5ms |
| Operating Force: | 4,5N |
| Operating Path: | 1,0mm |
| Operating Life/Cycles at Rated Switching Capacity: | 50x103 |
| Temperature Range: | -25...+85°C |
| Protection Class | |
| Front Side Contact Area to DIN 40050: | IP69K |
| Rear Side Contact Area: | IP40 |
