MOMENT 1XOM 230VAC/3A IP40 M19 VERLICHTING KNOP ROOD
€ 37,50
€ 30,99
Artikelnummer
MSMCS19-RD
- ArtikelnummerMSMCS19-RD
- MerkSCHURTER
- Aantal 5+ € 33,75 € 27,89
Features
• High-quality Stainless steel housing • Highly durable ceramic actuator with homogeneous illumination • Vandal-proof according to IP69K • For use in harsh environment • High-quality design • Reliable tactile feedback of input |
Technical Specifications |
Material | |
Housing: | Stainless Steel |
Actuator: | Ceramic |
Contacts: | Silver-plated |
Switching Voltage, Max.: | 250V AC |
Switching Current, Max.: | 3A, 250V AC/5A, 125V AC |
Switching Capacity, Max.: | 1250W |
Contact Resistance: | <30mOhm |
Insulation Resistance: | <100MOhm |
NO Pulse Time: | <5ms |
Operating Force: | 4,5N |
Operating Path: | 1,0mm |
Operating Life/Cycles at Rated Switching Capacity: | 50x103 |
Temperature Range: | -25...+85°C |
Protection Class | |
Front Side Contact Area to DIN 40050: | IP69K |
Rear Side Contact Area: | IP40 |
