DIN-RAIL 40MM VOEDING 60W 12V/5.0A

MODEL MDR-60-12

OUTPUT:
DC VOLTAGE 12V
RATED CURRENT 5A
CURRENT RANGE 0~ 5A
RATED POWER 60W
RIPPLE & NOISE (max.) Note.2 120mVp-p
VOLTAGE ADJ. RANGE 12~15V
VOLTAGE TOLERANCE Note.3 +/-1.0%
LINE REGULATION +/-1.0%
LOAD REGULATION +/-1.0%
SETUP, RISE TIME 500ms, 30ms/230VAC at full load
HOLD UP TIME (Typ.) 50ms/230VAC at full load

INPUT:
VOLTAGE RANGE 85 ~ 264VAC
FREQUENCY RANGE 47 ~ 63Hz
EFFICIENCY (Typ.) 86%
AC CURRENT (Typ.) 1A/230VAC
INRUSH CURRENT (Typ.) COLD START 36A/230VAC
LEAKAGE CURRENT <1mA / 240VAC

PROTECTION:
OVERLOAD
105 ~ 150% rated output power
Protection type : Constant current limiting, recovers automatically after fault condition is removed
OVER VOLTAGE 15.6 ~ 18V
Protection type : Shut down o/p voltage, re-power on to recover.

FUNCTION DC OK SIGNAL Relay contact rating(max.): 30V/1A resistive

DIMENSION: 40*90*100mm (W*H*D)
