DIN-RAIL 22.5MM VOEDING 10W 15V/0.67A
€ 16,95
€ 14,01
Artikelnummer
MDR1015
- ArtikelnummerMDR1015
- MerkMEANWELL
- Aantal 3+ € 16,09 € 13,30
Universal AC input/Full range
Protections: Short circuit / Overload / Over voltage
Cooling by free air convection
Can be installed on DIN rail TS-35/7.5 or 15
NEC class 2 / LPS compliant
Built in DC OK active signal
LED indicator for power on
No load power consumption<0.75W
100% full load burn-in test
Technical Specifications
Input Voltage: 85...264V AC (47...63Hz) 120...370V DC
Input Inrush Current, Max.: 70A
Leakage Current, Max.: 1mA
No Load Power Consumption, Max.: 0,75W
Over Load Protection: >105%
Withstand Voltage
I/P-O/P:3000V AC
I/P-FG: 1500V AC
O/P-FG: 500V AC
Operating Temperature: -20...+70°C
uitgangsspanning: 15V +/-3%
uitgangsstroom: 0.67A
max. vermogen: 10W
afmetingen: 22.5 x 90 x 100mm
gewicht: 170g
werktemperatuur: -20°C ~ 70°C
Protections: Short circuit / Overload / Over voltage
Cooling by free air convection
Can be installed on DIN rail TS-35/7.5 or 15
NEC class 2 / LPS compliant
Built in DC OK active signal
LED indicator for power on
No load power consumption<0.75W
100% full load burn-in test
Technical Specifications
Input Voltage: 85...264V AC (47...63Hz) 120...370V DC
Input Inrush Current, Max.: 70A
Leakage Current, Max.: 1mA
No Load Power Consumption, Max.: 0,75W
Over Load Protection: >105%
Withstand Voltage
I/P-O/P:3000V AC
I/P-FG: 1500V AC
O/P-FG: 500V AC
Operating Temperature: -20...+70°C
uitgangsspanning: 15V +/-3%
uitgangsstroom: 0.67A
max. vermogen: 10W
afmetingen: 22.5 x 90 x 100mm
gewicht: 170g
werktemperatuur: -20°C ~ 70°C
