LED VOEDING 5V/12A 60W IP67 BEHUIZING
€ 33,67
€ 27,83
Artikelnummer
LPV1005
- ArtikelnummerLPV1005
- MerkMEANWELL
- Aantal 3+ € 31,98 € 26,43
Features
Constant voltage design
UniversalAC input / Full range
Fully encapsulated with IP67 level
Withstand 300VAC surge input for 5 seconds
Protections: short circuit/over load/over voltage
Fully isolated plastic case
Cooling by free air convection
100% full load burn-in test
Low cost, high reliabillity
IP67, for indoor and outdoor installations
Suitable for LED lighting and moving sign applications
Input Voltage: 90...264V AC (47...63Hz)
Input Inrush Current, Max.: 75A
Over Load Protection: 110...150%
Withstand Voltage (I/P-O/P): 3000V AC
I/P = Input, O/P = Output
Operating Temperature: -25...+70°C
Weight: 630g
Dimensons 190x52x37mm (LxWXH)
Output Voltage: 5Vdc
Output Current Range: 0 - 12A
Output Power: 60W
Output Voltage Tolerance: 8%
Ripple & Noise: 80mVp-p
Typ. Efficiency: 80%
