LED VOEDING 36V/2.80A 100W IP67 BEHUIZING

Features

• Constant voltage design
• UniversalAC input / Full range
• Fully encapsulated with IP67 level
• Withstand 300VAC surge input for 5 seconds
• Protections: short circuit/over load/over voltage
• Fully isolated plastic case
• Cooling by free air convection
• 100% full load burn-in test
• Low cost, high reliabillity
• IP67, for indoor and outdoor installations
• Suitable for LED lighting and moving sign applications


Input Voltage: 90...264V AC (47...63Hz)
Input Inrush Current, Max.: 75A
Over Load Protection: 110...150%
Withstand Voltage (I/P-O/P): 3000V AC
I/P = Input, O/P = Output
Operating Temperature: -25...+70°C
Weight: 630g
Dimensons 190x52x37mm (LxWXH)

Output Voltage: 36Vdc
Output Current Range: 0 - 2,8A
Output Power: 100W
Output Voltage Tolerance: 5%
Ripple & Noise: 150mVp-p
Typ. Efficiency: 88%
