TRANSFORMATOR 1:10 4.6-340 OHM INGEGOTEN
€ 5,95
€ 4,92
Artikelnummer
LFT1505
- ArtikelnummerLFT1505
- MerkBrand
- Aantal 5+ € 5,35 € 4,42
Features
Two chamber bobbins with enamelled copper wire windings
EI19/6,7 core, EI19 cap, potted
PC pin terminals for PCB mounting
Side marking with transformation, part number and datecode
Technical Specifications
Test Voltage: 4kV/2s
Dimensions (LxWxH), Max.: 21x18,2x19,3mm
Transformation: 1:10
R primair: 4,6 Ohm
R secondair: 340 Ohm
Two chamber bobbins with enamelled copper wire windings
EI19/6,7 core, EI19 cap, potted
PC pin terminals for PCB mounting
Side marking with transformation, part number and datecode
Technical Specifications
Test Voltage: 4kV/2s
Dimensions (LxWxH), Max.: 21x18,2x19,3mm
Transformation: 1:10
R primair: 4,6 Ohm
R secondair: 340 Ohm
