LED VOEDING 24V/13.3A 320W IP65 BEHUIZING
€ 119,00
€ 98,35
Artikelnummer
HLG320H24A
- ArtikelnummerHLG320H24A
- MerkMEANWELL
- Aantal 3+ € 113,05 € 93,43
| Features |
| • Constant current and constant voltage • Independent control gear • Wide range input • Metal housing • Overload protection by current limiting, auto recovery • Protected against short circuit, overload, overvoltage, overtemperature • Built-in PFC circuit • For LED lighting applications • SELV Compliant • Safety standards: EN61347-1, EN61347-2-13 and others • EMC Standards: EN55015, EN61000-3-2 Class C, EN61000-3-3, EN61547 and others • 7 years manufacturer warranty • HLG-320H-_: IP67, voltage and current fixed, not dimmable • HLG-320H_A: IP65, output voltage and current limit adjustable via internal potentiometer, not dimmable • HLG-320H_B: IP67, dimming via implemented control line, 3 in 1 dimming function (1...10V DC, PWM, 100k Ohm potentiometer) • HLG-320H_AB: IP65, current limit adjustable via internal potentiometer, dimming via implemented control line, 3 in 1 dimming function (1...10V DC, PWM, 100k Ohm potentiometer) |
 |
| Technical Specifications |
|
|
| Input Voltage: | 90...305V AC (47...63Hz) |
| 127...431V DC | |
| Input Inrush Current, Max.: | 70A |
| Withstand Voltage | |
| I/P-O/P: | 3750V AC |
| I/P-FG: | 2000V AC |
| O/P-FG: | 1500V AC |
| Operating Temperature: | -40...+90°C |
| Dimensions(LxWxH): | 252x90x43.8mm |
| Weight: | 1880g |
