LED VOEDING 24V/1.25A 30W IP67 BEHUIZING
€ 45,96
€ 37,98
Artikelnummer
SLT3024VFC
- ArtikelnummerSLT3024VFC
- MerkSELF
- Aantal 5+ € 43,66 € 36,08
Features
| • Independent power supply • Class II protection, SELV output • Flicker-free design • Constant voltage • IP20 • Protected against over load, short circuit, over voltage and over temperature • EN61347-1, EN61347-2-13, EN55015, EN61000-3-2 etc. • For LED lighting applications • 5 years warranty |
 |
| Technical Specifications |
|
|
| Input Voltage: | 220...240V AC |
| Input Inrush Current: | 18A |
| Operating Temperature: | -20...+40°C |
| Nominal Life-Time (Tc=85°C): | 35.000h |
| Weight | |
| SLT30-12VFG: | 135g |
| SLT30-24VFG: | 125g |
|
|
| Part Nr. | UA | IA | PA | URN | h |
| [V] | [A] | [W] | [mVp-p] | [%] | |
| SLT30-12VFG | 12 | 0...1,25 | 30 | 90 | 83,5 |
| SLT30-24VFG | 24 | 0...1,25 | 30 | 100 | 84,5 |
| UA = Output Voltage, IA = Output Current, PA = Output Power, URN = Ripple & Noise, h = Efficiency | |||||
