LED VOEDING 15V/1.00A 15W IP30 BEHUIZING
€ 12,50
€ 10,33
Artikelnummer
APV1615
- ArtikelnummerAPV1615
- MerkMEANWELL
- Aantal 3+ € 11,87 € 9,81
Features
| • Independent power supply • Universal input • Plastic enclosure IP42 • Overload protection, pulsing hiccup shutdown, auto recovery • Protections: short circuit/over load/over voltage • Suitable for LED lighting and moving sign applications • Constant voltage |
 |
| Technical Specifications |
|
|
| Input Voltage: | 90...264V AC (47...63Hz) |
| 127...370V DC | |
| Input Inrush Current, Max.: | 50A |
| Over Current Protection: | 105 % |
| Withstand Voltage (I/P-O/P): | 3750V AC |
| Operating Temperature: | -30...+70°C |
| Weight: | 100g |
| I/P = Input, O/P = Output |
|
|
|
| Part Nr. | UA | IA | PA | DUA | URN | h |
| [V] | [A] | [W] | [%] | [mVp-p] | [%] | |
| APV1605 | 5 | 0...2,6 | 13 | 5 | 100 | 76 |
| APV1612 | 12 | 0...1,25 | 15 | 5 | 120 | 80 |
| APV1615 | 15 | 0...1 | 15 | 5 | 120 | 81 |
| APV1624 | 24 | 0...0,67 | 16,08 | 5 | 150 | 83 |
| UA = Output Voltage, IA = Output Current Range, PA = Output Power, URN = Ripple & Noise, h = Typ. Efficiency | ||||||
