LED VOEDING 12V/6.25A 72W IP67 BEHUIZING
€ 58,50
€ 48,35
Artikelnummer
SLT7512VFC
- ArtikelnummerSLT7512VFC
- MerkSELF
- Aantal 3+ € 55,58 € 45,93
Features
| • Independent power supply • Class II protection, SELV output • Flicker-free design • Constant voltage • IP20 • Protected against over load, short circuit, over voltage and over temperature • EN61347-1, EN61347-2-13, EN55015, EN61000-3-2 etc. • For LED lighting applications • 5 years warranty |
 |
| Technical Specifications |
|
|
| Input Voltage: | 220...240V AC |
| Input Inrush Current: | 46A |
| Operating Temperature: | -20...+45°C |
| Nominal Life-Time (Tc=90°C): | 30.000h |
| Weight: | 162g |
|
|
| Part Nr. | UA | IA | PA | URN | h |
| [V] | [A] | [W] | [mVp-p] | [%] | |
| SLT75-12VFG | 12 | 0...6,25 | 75 | 500 | 90 |
| SLT75-24VFG | 24 | 0...3,1 | 75 | 200 | 90 |
| UA = Output Voltage, IA = Output Current, PA = Output Power, URN = Ripple & Noise, h = Efficiency | |||||
