LED DRIVER INPUT 9.5-32V / OUTPUT 12.5-50VDC 500MA 25W DIMBAAR PWM
€ 12,95
€ 10,70
Artikelnummer
LDH25-50W
- ArtikelnummerLDH25-50W
- MerkMEANWELL
- Aantal 5+ € 11,65 € 9,63
| eatures |
| • DC/DC step-up converter • Constant current output • Wide input voltage range • Dimming by 0...10V DC, PWM • Suitable for LED and lighting applications • Protection against Short circuit and over voltage • EMV standards: EN 55015 • Safety standards: IEC 61347-1, IEC 61347-2-13 • 3 years manufacturer warranty • LDH-_: with solder pins • LDH-_W: with wires |
 |
| Technical Specifications |
|
|
| Output Current Tolerance: | +-5% |
| Operating Temperature: | -40...+70°C |
| Cable Lenght | |
| LDH-25-W: | 10cm |
| Dimensions: | 52,4x27,2x24mm |
| Weight: | |
| LDH-25-W: | 57g |
|
|
| Part Nr. | UE | UA | IA | h |
| [V] | [V] | [A] | [%] | |
| LDH25-25W | 9,5...32 | 12,5...84 | 0,25 | 94 |
| LDH25-35W | 9,5...32 | 12,5...72 | 0,35 | 95 |
| LDH25-50W | 9,5...32 | 12,5...50 | 0,5 | 94 |
| LDH25-70W | 9,5...32 | 12,5...36 | 0,7 | 95,5 |
| UE = Input Voltage, UA = Output Voltage, IA = Output Current Range, URN = Ripple & Noise, h = Efficiency | ||||
|
||||
| Note |
| The LDH drivers are step-down converters. Minimum output voltage will only be achieved with minimum input voltage. The minimum output voltage is always higher than the input voltage. |
