LED DRIVER INPUT 9.5-32V / OUTPUT 12.5-37VDC 1750MA 64.7W DIMBAAR PWM
€ 21,95
€ 18,14
Artikelnummer
LDH65-175W
- ArtikelnummerLDH65-175W
- MerkMEANWELL
- Aantal 5+ € 19,75 € 16,32
| Features |
| • DC/DC step-up converter • Constant current output • Wide range input • Dimming by 0...10V DC, PWM • Suitable for LED and lighting applications • Protection against Short circuit and over voltage • Cooling by free convention • EMC standards: EN 55015 • Safety standards: IEC 61347-1, IEC 61347-2-13 • 3 years manufacturer warranty • LDH-: Version with solder pins • LDH-_W: Version with strands |
 |
| Technical Specifications |
|
|
| Output Current Tolerance: | +-5% |
| Operating Temperature: | -40...+60°C |
| Cable Lenght | |
| LDH-65-W: | 10cm |
| Dimensions: | 75x53x,22,7mm |
| Weight: | |
| LDH-65-W: | 159g |
|
|
| Artikel | UE | UA | IA | h |
| [V] | [V] | [A] | [%] | |
| LDH65-70W | 9,5...32 | 12,5...80 | 0,7 | 95 |
| LDH65-105W | 9,5...32 | 12,5...63 | 1,05 | 95,5 |
| LDH65-140W | 9,5...32 | 12,5...46 | 1,4 | 95 |
| LDH65-175W | 9,5...32 | 12,5...37 | 1,75 | 96 |
| UE = Input Voltage, UA = Output Voltage, IA = Output Current , h = Efficiency | ||||
|
||||
| Note |
| The LDH are step-up converters. The output voltage must always be at least 3 volts higher than the input voltage. |
