LED DRIVER 3-8VDC 500MA 4W
€ 12,95
€ 10,70
Artikelnummer
RACD04-500
- ArtikelnummerRACD04-500
- MerkRECOM
- Aantal 5+ € 11,65 € 9,63
| Features |
| • Universal input • Plastic enclosure IP65 • Overload protection, shutdown, auto recovery • Protections: short circuit/over load • Suitable for LED lighting and moving sign applications • Constant current • EN61347, UL 8750 |
 |
| Technical Specifications |
|
|
| Input Voltage: | 90...264V AC (47...63Hz) |
| Input Inrush Current, Max.: | 10A |
| Withstand Voltage (I/P-O/P): | 3750V AC |
| Operating Temperature: | -20...+50°C |
| Weight: | 40g |
| I/P = Input, O/P = Output |
|
|
|
| Part Nr. | UA |
IA |
PA |
IRN |
h |
| [V] | [mA] | [W] | [Ap-p] | [%] | |
| RACD04-350 | 3...12 | 350 | 4,2 | 0,08 | 77 |
| RACD04-500 | 3...8 | 500 | 4 | 0,09 | 75 |
| RACD04-700 | 3...6 | 700 | 4,2 | 0,09 | 72 |
| UA = Output Voltage, IA = Output Current, PA = Output Power, IRN = Ripple & Noise, h = Typ. Efficiency | |||||
