• Universal input • Plastic enclosure IP67 • Overload protection, current limiting, auto recovery • Protections: short circuit/over load/over voltage • Protection Class 2 • Fixed output current
Technical Specifications
Input Voltage:
180...305V AC (47...63Hz)
254...431V DC
Input Inrush Current, Max.:
40A
Withstand Voltage (I/P-O/P):
3000V AC
Operating Temperature:
-25...+50°C
Weight:
740g
I/P = Input, O/P = Output
Part Nr.
UA
IA
PA
DIA
URN
h
[V]
[mA]
[W]
[%]
[Vp-p]
[%]
LPC-150-350
215...430
350
150,5
5
2
90
LPC-150-500
150...300
500
150
5
1,5
90
LPC-150-700
107...215
700
150,5
5
1
90
LPC-150-1050
72...144
1050
151,2
5
1
90
LPC-150-1400
54...108
1400
151,2
5
1
90
LPC-150-1750
43...86
1750
150,5
5
1
90
LPC-150-2100
36...72
2100
151,2
5
1
90
LPC-150-2450
31...62
2450
151,9
5
1
90
LPC-150-2800
27...54
2800
151,2
5
1
90
LPC-150-3150
24...48
3150
151,2
5
1
90
UA = Output Voltage, IA = Output Current Range, PA = Output Power, DIA = Output Current Tolerance, URN = Ripple & Noise, h = Typ. Efficiency
Note
Devices only for use in equipment with another primary purpose such as photocopiers, overhead projectors and slide projectors or for scale illumination or indication purposes. Suitable for indoor use and outdoor use without direct sunlight exposure. Please avoid immerse in the water over 30 minutes.
