LED DRIVER 2-59VDC 350MA 20W
€ 25,95
€ 21,45
Artikelnummer
RACD20-35L
- ArtikelnummerRACD20-35L
- MerkRECOM
- Aantal 5+ € 23,35 € 19,30
eatures
| • Universal input • Constant current • Not dimmable • Plastic housing IP20 • Low profile (13mm high) • Overload protection by shutdown, auto recovery • Protected against short circuit, overload • For LED and lighting applications • Safety standards: IEC 61347-1; IEC 61347-2-13; EN 61347-1; EN 61347-2-13 • EMC standards: EN 55015 • 3 years manufacturer warranty |
 |
| Technical Specifications |
|
|
| Input Voltage: | 198...264V AC (47...63Hz) |
| Input Inrush Current, Max.: | 8A |
| No-load power, less than: | 0,5W |
| Withstand Voltage (I/P-O/P): | 3750V AC |
| Operating Temperature: | -20...+45°C |
| Dimensions(LxWxH): | 128x50x13mm |
| Weight: | 75g |
| I/P = Input, O/P = Output |
|
|
|
| Part Nr. | UA | IA | PA | IRN | h |
| [V] | [mA] | [W] | [Ap-p] | [%] | |
| RACD20-350-LP | 2...59 | 350 | 21 | 0,05 | 86 |
| RACD20-500-LP | 2...40 | 500 | 20 | 0,05 | 85 |
| RACD20-700-LP | 2...31 | 700 | 22 | 0,05 | 85 |
| UA = Output Voltage, IA = Output Current, PA = Output Power, IRN = Ripple & Noise, h = Typ. Efficiency | |||||
