LED DRIVER 2-4.3VDC 700MA 3W
€ 9,95
€ 8,22
Artikelnummer
SLT3700
- ArtikelnummerSLT3700
- MerkSELF
- Aantal 5+ € 8,94 € 7,39
| Features |
| • Independent power supply • Class II protection, SELV output • Constant current • IP20 • Protected against over load, short circuit, over voltage and over temperature • EN61347-1, EN61347-2-13, EN55015, EN61000-3-2 etc. • For LED lighting applications |
 |
| Technical Specifications |
|
|
| Input Voltage: | 220...240V AC |
| Input Inrush Current: | 18A |
| Operating Temperature: | -20...+45°C |
| Nominal Life-Time | |
| SLT3-350IS-1 (Tc=70°C): | 30.000h |
| SLT3-700IS-1 (Tc=85°C): | 30.000h |
| Weight: | 30g |
|
|
| Part Nr. | UA |
IA |
PA |
IRN |
h |
| [V] | [mA] | [W] | [mAp-p] | [%] | |
| SLT3-350IS-1 | 4...9 | 350 | 3 | 100 | 72 |
| SLT3-700IS-1 | 2...4,2 | 700 | 3 | 200 | 67 |
| UA = Output Voltage, IA = Output Current, PA = Output Power, IRN = Ripple & Noise, h = Efficiency | |||||
