LED VOEDING 36V/6.7A 241W IP65 BEHUIZING DIMBAAR

Universal AC input / Full range
Built-in active PFC function
Protections: Short circuit / Over current / Over voltage / Over temperature
Cooling by free air convection
OCP point adjustable through output cable or internal potentiometer
IP67 / IP65 design for indoor or outdoor installations
Type HL LED Driver for use in Class ¢¹, Division 2 hazardous location luminaires
Three in one dimming function (1~10Vdc or PWM signal or resistance)
Suitable for LED lighting and street lighting applications
Compliance to worldwide safety regulations for lighting
Suitable for dry / damp / wet locations

Uitgang
dc spanning : 36V
Stroom (max.) : 6.7A
Vermogen : : 241W
Ripple & Noise (max.) : 250mVp-p
Spanning instelbaar : 33.5 ~ 38.5V
IP-classificatie : IP65
3in1 dimming function (external voltage 1...10V DC, PWM, potentiometer)
Adjustable output current over control cable


Ingang spanning : 90 ~ 264VAC 127 ~ 373VDC
Frequentie : 47 ~ 63Hz
