GESCHAKELDE VOEDING SINGLE OUTPUT 75W 48V/1.65A PFC
€ 47,89
€ 39,58
Artikelnummer
RSP7548
- ArtikelnummerRSP7548
- MerkMEANWELL
- Aantal 3+ € 45,50 € 37,60
Technical Specifications
 |
|
| Input Voltage: | 85...264V AC (47...63Hz) |
| 120...370V DC | |
| Input Inrush Current, Max.: | 35A |
| Leakage Current, Max.: | 2mA |
| Output Voltage Adjustment: | -5/+10% |
| Over Load Protection: | 105...135% |
| Withstand Voltage | |
| I/P-O/P: | 3750V AC |
| I/P-FG: | 2000V AC |
| O/P-FG: | 500V AC |
| Operating Temperature: | -25...+70°C |
| Weight: | 440g |
| I/P = Input, O/P = Output, FG = Frame Ground |
|
|
|
| Part Nr. | UA | IA | PA | DUA | URN | h |
| [V] | [A] | [W] | [%] | [mVp-p] | [%] | |
| RSP-75-3.3 | 3,3 | 0...15 | 49,5 | 2 | 80 | 76 |
| RSP-75-5 | 5 | 0...15 | 75 | 2 | 80 | 82 |
| RSP-75-7.5 | 7,5 | 0...10 | 75 | 2 | 80 | 84 |
| RSP-75-12 | 12 | 0...6,3 | 75,6 | 2 | 120 | 85 |
| RSP-75-13.5 | 13,5 | 0...5,6 | 75,6 | 2 | 120 | 85 |
| RSP-75-15 | 15 | 0...5 | 75 | 2 | 120 | 86 |
| RSP-75-24 | 24 | 0...3,2 | 76,8 | 1 | 120 | 87 |
| RSP-75-27 | 27 | 0...2,8 | 75,6 | 1 | 120 | 88 |
| RSP-75-48 | 48 | 0...1,6 | 76,8 | 1 | 200 | 89 |
| UA = Output Voltage, IA = Output Current Range, PA = Output Power, Uadj = Output Voltage Adjustment, DUA = Output Voltage Tolerance, URN = Ripple & Noise, h = Efficiency | ||||||
